Application: Indoor
Product Category: Linear Light
Type: Corner Module, Lines, Standard Curve
DIY: CNC Cover-R1, CNC Cover-R2, CNC Cover-R3, CNC Cover-Mid 105, CNC Cover-Mid 119, CNC Cover-Mid 147, CNC Cover-Mid 182, CNC Cover-Mid 238, CNC Cover-Mid 280, CNC Cover-Mid 560, C660 1/2 of a Circle, C960 1/2 of a Circle
Mounting Type: Pendant
Trim: Circle, Square
Housing Color: Black, White
Diffuser: Microprismatic
IP: 20
CCT: 3000K, 4000K
CRI: 80, 90
LED Output: ≤15000lm
System Output: ≤7050lm↓3750lm↑
Lifetime: 50000h@L80B10
LED Chip: Lumileds
Beam Angle: 80°, 80°↓105°↑
UGR: <19
LED Driver: DALI Dim, ON-OFF
LED Power: 10W, 11W, 14W, 15W, 21W, 24W, 27W, 29W, 34W, 36W, 42W, 47W, 47W↓21W↑, 52W, 57W, 81W
System Power: 11W↓5W↑, 12W, 13W, 17W, 23W, 24W, 24W↓9W↑, 27W, 27W↓12W↑, 30W, 33W, 33W↓14W↑, 40W, 40W↓18W↑, 52W, 52W↓24W↑, 64W, 64W↓26W↑
LED Voltage: 28V
LED Current: 350mA, 400mA, 500mA, 550mA, 750mA, 850mA, 950mA, 1050mA, 1200mA, 1300mA, 1500mA, 1700mA, 1900mA, 2050mA, 2400mA, 2900mA
Measurements: 280mm x 280mm, 470mm x 470mm, 560mm x 60mm, 620mm x 620mm, 1050mm x 60mm, 1190mm x 60mm, 1317mm x 60mm, 1470mm x 60mm, 1788mm x 60mm, 1820mm x 60mm, 2380mm x 60mm, 2800mm x 60mm
Net Weight: 900g, 1000g, 1300g, 1700g, 1850g, 1900g, 2100g, 2375g, 2625g, 2800g, 2850g, 3180g, 3800g, 4400g, 4450g, 4900g
Gross Weight: 1150g, 1250g, 1300g, 1600g, 2100g, 2300g, 2400g, 2600g, 2650g, 2900g, 3500g, 3600g, 4000g, 4200g, 4600g, 5200g, 5600g, 6100g
Measurements: 560mm x 60mm
Measurements: 1050mm x 60mm
Measurements: 1190mm x 60mm
Measurements: 1470mm x 60mm
Measurements: 1820mm x 60mm
Measurements: 2380mm x 60mm
Measurements: 2800mm x 60mm
